YAQIN MS-845 Mono Block Power Amplifier + Preamp pre-amplifier

Product Price: $2,514.00 USD

  • Product Model: Model: MUIA983358
  • Product Weight: Shipping Weight: 77kg
  • Product Quantity: 0 Units in Stock

Please Choose:

Sold Out



YAQIN MS-845 Class A single-ended vacuum Tube Mono Block Power Amplifier (a pair) add one pre-amp
100% Brand New



All items guaranteed 100% BRAND NEW in the original edition Box.



preamp and power amp is a sub-structure, reasonable layout, lower noise.
Before the class is "SRPP" circuit, and increase the cathode output device, wide frequency response, low output impedance.
After amplification for low-level resistance of the power transistor (845), and A single-ended amplifier, the sound quality is good.
After the circuit level to promote the "SRPP" circuit, and for the dual parallel, wide frequency response, pushing strong.
Japan imported the audio output transformer using dedicated oriented silicon steel Z11 (0.35mm thick) and oxygen-free high strength enameled wire and special winding process multi-group production, so that the machine wide frequency response, to ensure that the machine high, medium and low frequency sounds good , transparent and powerful.
This machine adopts foreign name Factory sound dedicated enthusiast and non-polarized electrolytic (MKP) Need for high-quality imported French Suren gold blocking capacitors and manufacturing, the main audio channel dedicated to use imported from Japan (ALPS) volume motor potentiometer, with quiet background music, low noise, no sound pollution and durable.
High-voltage power supply for the automatic delay control, can effectively extend the tube life, and with remote control function.

Electrical Specifications

Output Power: 25W + 25W (8Ω)
Distortion: ≤ 2.5% (1kHz)
Frequency response: 10Hz - 40kHz (-2dB)
SNR: ≥ 86dB (A)
Input Sensitivity: ≤ 0.2V
Load Impedance: 4Ω - 8Ω
Tubes: preamp: 12AX7 × 2 12AU7 × 1
power amp : 12AU7 × 2 845 × 1
Power Voltage: AC110V/220V 60Hz/50Hz (110V ,120V,230V,240V,version will take 3-14 work days to order). 220v is in stock.
Volume: preamp: 275mm x 195mm x 390mm (D x W x H)
power amp: 315mm x 395mm x 435mm (D x W x H)
Gross weight: preamp: 13kg
Powe amp: 32kg x2 (a pair) = 64 kg
