Shanling CD3.1 Hi-end vacuum tube CD player XLR USB output

Product Price:

  • Product Model: Model: MUIA983491
  • Product Weight: Shipping Weight: 15kg
  • Product Quantity: 0 Units in Stock

Please Choose:

Sold Out


Shanling CD3.1 Hi-end vacuum tube CD player
XLR, USB, digita, analog RCA Output
 Brand New
There is a update version or Shanling CD3.1 link below



All items guaranteed 100% BRAND NEW in the original edition Box.



 ◎ Sanyo HD870 head + Philips SAA7824 servo system
 ◎ panel side panels and roof panel and an integrated all-aluminum design, CD movement mounted on thick 4.9MM cover, can effectively play the biggest shock, and improve the reading accuracy of the servo system
 ◎ electric roof access doors to the belt-driven design
 ◎ using BB's PCM1704 do two D / A converter plus SM5847 to do digital filtering, which greatly simplifies the DAC low-pass filter circuit to achieve the flattest frequency response, making the sound more natural and pure
 ◎ using four top OPA627 op-amp
 ◎ using two AD847 and two Russian-made military-grade brand EH 6H30 guts to do the buffer output
 ◎ using BB's SRC4193 do upconversion
 ◎ coaxial, balanced digital output
 ◎ coaxial, USB digital input
 ◎ tube line output
 ◎ simulation, digital dual-transformer power supply
 ◎ Standby power consumption less than 1W
 ◎ can receive (96KHz/24bit) USB digital signal
 ◎ size (W x D x H): 460 x 403 x 132mm
 ◎ weight: about 12.7 Kg

 Technical Specifications:

 ◎ non-equilibrium output level : 2.3V

 ◎ Balance : 4.6V output level

 ◎ Frequency response : 20Hz - 20KHz (- 0.5dB)

 ◎ Signal to Noise Ratio (A - W) :> 107dB (RCA)
                                                      :> 115dB (XLR)

 ◎ THD : <0.02% (RCA)
               <0.002% (XLR)

 ◎ USB to receive the maximum rate : 96KHz/24bit (USB2.0)

 ◎ Maximum Power : <60W

 ◎ Dimensions (W x D x H) : 460 x 403 x 132mm

 ◎ Power supply voltage: 110/220V 60Hz/50Hz
                                      (100V, 110V, 120V, 127V, 230V, 240V version will
                                      take 3-14 work days to order),
                                      220V version is in stock

 ◎ Net weight : about 12.7 kg

 ◎ Gross weight : 15Kg

This product was added to our catalog on Sunday 21 December, 2014.
